Тяло и контратяло
| Вид |
Описание на материала |
Символ |
Код |
|
SIC
|
Silicone Carbide, Sintered Pressureless
|
SSiC
|
Q1
|
|
|
Silicone Carbide, Sintered Pressureless (shrunk-in)
|
|
Q12
|
|
|
Silicone Carbide, Reaction bonded
|
RBSiC
|
Q2
|
|
|
Silicone Carbide, Reaction bonded (shrunk-in)
|
|
Q22
|
|
|
Reaction Silicon Carbide with Graphite
|
|
Q3
|
|
|
Sintered Silicon Carbide with SB
|
|
Q4
|
|
AI203
|
Ceramic (Alumina)
|
99.5% AI2O3
|
V
|
|
|
Ceramic (Alumina)
|
99% AI2O3
|
V1
|
|
|
Ceramic (Alumina)
|
95% AI2O3
|
V2
|
|
|
Cermet
|
Fe + AI2O3
|
V3
|
|
TC
|
Co-binder Tungsten Carbide
|
YG6, YGB
|
U1
|
|
|
Co-binder Tungsten Carbide (shrunk-in)
|
|
U12
|
|
|
Ni-binder Tungsten Carbide
|
M106, M108
|
U2
|
|
|
Ni-binder Tungsten Carbide (shrunk-in)
|
|
U22
|
|
|
NiCrMo-binder Tungsten Carbide
|
W7
|
U3
|
|
|
NiCrMo-binder Tungsten Carbide (shrunk-in)
|
|
U32
|
|
Carbon
|
Antimony Impreg. Carbon Graphite
|
|
A
|
|
|
Babbit Alloy Impreg. Carbon Graphite
|
|
A1
|
|
|
Cooper Impreg. Carbon Graphite
|
|
A2
|
|
|
Resin Impregnated Carbon Graphite (Furan)
|
|
B
|
|
|
Resin Impregnated Carbon Graphite (Epoxy)
|
|
B1
|
|
|
Resin Impregnated Carbon Graphite (Phenol-formaldehyde)
|
|
B2
|
|
|
Hot-pressing Carbon
|
|
B5
|
|
Metal
|
Stainless Steel
|
304
|
F
|
|
|
Stainless Steel
|
304L
|
F1
|
|
|
Stainless Steel
|
316
|
G
|
|
|
Stainless Steel
|
316L
|
G1
|
|
|
Tin Bronze
|
ZQSn6-6-3
|
S1
|
|
|
High silicon cast iron
|
|
S2
|
|
|
High nickel cast iron
|
|
S3
|
|
Plastic
|
PTFE, glassfibre reinforced
|
|
Y1
|
|
|
PTFE, carbon reinforced
|
|
Y2
|
ВТОРИЧНО УПЛЪТНЕНИЕ (ЕЛАСТОМЕР)
Вторично уплътнение (еластомер)
| Вид |
Описание на материала |
Символ |
Код |
|
Rubber
|
Nitrile (NBR)
|
NBR
|
P
|
|
|
Ethylene Propylene (EPDM)
|
EPR
|
E
|
|
|
Fluorocarbon (Viton)
|
FPM
|
V
|
|
|
Silicic Rubber
|
MVQ
|
S
|
|
|
Chloroprene
|
CR
|
N
|
|
|
Hydrogen Nitrile
|
HNBR
|
H
|
|
|
Perfluoroelastomer (Kalrez, Chemraz)
|
|
K
|
|
PTFE
|
Pure PTFE
|
PTFE
|
T
|
|
|
PTFE, glassfibre reinforced
|
|
T2
|
|
|
PTFE, carbon reinforced
|
|
T3
|
|
PTFE wrapped
|
FPM, with PTFE wrapped
|
PTFE+FPM
|
M1
|
|
|
EPR, with PTFE wrapped
|
PTFE+EPR
|
M2
|
|
|
MVQ, with PTFE wrapped
|
PTFE+MVQ
|
M3
|
|
Expanded graphite
|
Expanded graphite
|
|
G
|
ПРУЖИНА
Пружина
| Вид |
Описание на материала |
Символ |
Код |
|
|
Hastelloy C-4 Alloy
|
Hast.C4
|
M
|
|
|
Stainless Steel
|
304
|
F
|
|
|
Stainless Steel
|
304L
|
F1
|
|
|
Stainless Steel
|
316
|
G
|
|
|
Stainless Steel
|
316L
|
G1
|
|
|
65Mn Coated witch Chrome
|
65Mn
|
G8
|
Метални части
| Вид |
Описание на материала |
Символ |
Код |
|
|
Normal Stainless Steel
|
2Cr13
|
F2
|
|
|
Stainless Steel
|
304
|
F
|
|
|
Stainless Steel
|
304L
|
F1
|
|
|
Stainless Steel
|
316
|
G
|
|
|
Stainless Steel
|
316L
|
G1
|
|
|
Hastelloy C-4 Alloy
|
Hast.C4
|
M
|
|
|
Hastelloy B-2 Alloy
|
Hast.B2
|
M1
|
|
|
Carpenter
|
Carp.20
|
M3
|
|
|
Monel
|
Monel.K500
|
M4
|
|
|
Hastelloy C-276 Alloy
|
Hast. C-276
|
M5
|
|
|
Pure Titanium
|
TA2
|
T2
|
|
|
Carpenter
|
Carp.42
|
T4
|
|
|
Deposit induration Stainless Steel
|
AM350
|
T6
|
|
|
08F Coated with Chrome
|
Q235-A
|
C
|
|
|
Brass
|
H62
|
H
|
